Open Type Thin Section Radial Contact Ball Bearings (Type C)

Introduction

Open type thin section radial contact ball bearings（type c), consists of an outer ring, an inner ring, a group of steel balls and a group of Paoter frame.

Thin section radial contact ball bearings mainly bear radial load, when it only bear radial load, contact angle is zero. When Thin section radial contact ball bearings have a large radial clearance, has a certain angular contact bearing performance, can also withstand radial load and axial load at the same time. Can withstand large axial load, Thin section radial contact ball bearings friction coefficient is very small, the limit speed is also very high.

In the high speed and should not be used thrust ball bearings can also be used to withstand pure axial load. Compared with other types of bearings of the same size, these bearings have a small coefficient of friction and a high limiting speed.

Thin section radial contact ball bearings are mostly brass stamping cages, small sizes are made of nylon cages, and they can also be customized according to customers’ requirements.

Thin section radial contact ball bearings are characterized by simplicity, light weight and compactness. In order to meet the needs of customers, Thin section radial contact ball bearings have reduced the overall weight.

Thin section radial contact ball bearings are single row radial ball bearings of conventional design. They are mainly subject to radial loads. Their inner and outer rings are specially displaced so that the number of balls that can be loaded is approximately half that of a full complement of rollers. Although deep groove ball bearings are primarily used to carry radial loads, they can also carry a limited amount of unidirectional thrust loads from one direction and are generally used in conjunction with another bearing. However, if axial loading is an important factor, it is recommended that angular contact ball bearings are more suitable.

Thin section radial contact ball bearings are mostly made of Gcr15 and stainless steel 440C and 9cr18.

Open Type Thin Section Radial Contact Ball Bearings (Type C) are classified as follows

Type KAA cross-section size 4.763mm, steel ball size 2.381mm, bore size 25.4mm-44.45mm.
Type KA cross-section size 6.35mm, ball size 3.175mm, bore size 50.8mm-355.6mm.
Type KB cross-section size 7.938mm, ball size 3.969mm, bore size 50.8mm-508mm.
Type KC cross-section size 9.525mm, ball size 4.762mm, bore size 101.6mm-635mm.
Type KD cross-section size 12.7mm, ball size 6.35mm, bore size 101.6mm-635mm.
Type KF cross-section size 19.05mm, ball size 9.525mm, bore size 101.6mm-762mm.
Type KG cross-section size 25.4mm, ball size 12.7mm, bore size 101.6mm-1016mm.

Open Type Thin Section Radial Contact Ball Bearings (Type C) Product Features

1. Slim Design:

The open type thin section design of Type C bearings allows for a compact and lightweight solution, making them ideal for applications with limited space.

2. Radial Contact:

These bearings are specifically designed to handle radial loads, providing excellent support for applications where radial force is a primary concern.

3. High Precision:

Type C bearings are manufactured to strict tolerances, ensuring precision and accuracy in their performance. This makes them suitable for applications requiring fine control and accuracy.

4. Axial Load Capability:

In addition to their primary function of handling radial loads, Type C bearings also exhibit a certain degree of axial load capacity, enhancing their versatility in various applications.

5. Versatility:

The design of Type C bearings allows for versatility in application, making them suitable for a wide range of industries, including robotics, medical devices, aerospace, and automation.

Open Type Thin Section Radial Contact Ball Bearings (Type C) Applications

1. Robotics:

Type C bearings find extensive use in robotic applications due to their compact design and ability to support radial loads, contributing to the efficiency and precision of robotic movements.

2. Medical Devices:

The slim profile and precision of Type C bearings make them well-suited for medical devices where space is limited, and precise movement is critical.

3. Aerospace:

In aerospace applications, where weight and space are crucial factors, Type C bearings are used to provide reliable and efficient radial load support in a lightweight design.

4. Automation:

Type C bearings play a vital role in various automated systems, ensuring smooth and precise motion control in manufacturing and assembly processes.

Open Type Thin Section Radial Contact Ball Bearings (Type C) Product model

LKPB Number	Boundary dimensions (inch/mm)					Radial		Weight	Interchange
LKPB Number	d	D	H	L1	L2	Cor	Cr	Kg	NTN	KAYDON	SILVERTHIN
KAA10CL0	1	1.375	0.1875	1.142	1.236	1290	835	0.012	KRS010	KAA10CL0	SAA10CL0
KAA10CL0	25.4	34.925	4.763	29	31.4	1290	835	0.012	KRS010	KAA10CL0	SAA10CL0
KAA15CL0	1.5	1.875	0.1875	1.642	1.736	1780	1000	0.018	KRS015	KAA15CL0	SAA15CL0
KAA15CL0	38.1	47.625	4.763	41.7	44.1	1780	1000	0.018	KRS015	KAA15CL0	SAA15CL0
KAA17CL0	1.75	2.125	0.1875	1.89	1.985	2040	1070	0.02	KRS017	KAA17CL0	SAA17CL0
KAA17CL0	44.45	53.975	4.763	48	50.4	2040	1070	0.02	KRS018	KAA17CL1	SAA17CL1
KA020CP0	2	2.5	0.25	2.186	2.134	3020	1740	0.048	KRA020	KA020CP0	SA020CP0
KA020CP0	50.8	63.5	6.35	55.5	58.8	3020	1740	0.048	KRA020	KA020CP0	SA020CP0
KA025CP0	2.5	3	0.25	2.686	2.814	3690	1960	0.059	KRA025	KA025CP0	SA025CP0
KA025CP0	63.5	76.2	6.35	68.2	71.4	3690	1960	0.059	KRA025	KA025CP0	SA025CP0
KA030CP0	3	3.5	0.25	3.186	3.314	4400	2160	0.068	KRA030	KA030CP0	SA030CP0
KA030CP0	76.2	88.9	6.35	80.9	84.2	4400	2160	0.068	KRA030	KA030CP0	SA030CP0
KA035CP0	3.5	4	0.25	3.686	3.814	5070	2350	0.082	KRA035	KA035CP0	SA035CP0
KA035CP0	88.9	101.6	6.35	93.6	96.9	5070	2350	0.082	KRA035	KA035CP0	SA035CP0
KA040CP0	4	4.5	0.25	4.186	4.314	5730	2530	0.09	KRA040	KA040CP0	SA040CP0
KA040CP0	101.6	114.3	6.35	106.3	109.6	5730	2530	0.09	KRA040	KA040CP0	SA040CP0
KA042CP0	4.25	4.75	0.25	4.436	4.564	6090	2620	0.095	KRA042	KA042CP0	SA042CP0
KA042CP0	107.95	120.65	6.35	112.7	115.9	6090	2620	0.095	KRA042	KA042CP0	SA042CP0
KA045CP0	4.5	5	0.25	4.686	4.814	6400	2700	0.1	KRA045	KA045CP0	SA045CP0
KA045CP0	114.3	127	6.35	119	122.3	6400	2700	0.1	KRA045	KA045CP0	SA045CP0
KA047CP0	4.75	5.25	0.25	4.936	5.064	6760	2790	0.104	KRA047	KA047CP0	SA047CP0
KA047CP0	120.65	133.35	6.35	125.4	128.6	6760	2790	0.104	KRA047	KA047CP0	SA047CP0
KA050CP0	5	5.5	0.25	5.186	5.314	7070	2880	0.109	KRA050	KA050CP0	SA050CP0
KA050CP0	127	139.7	6.35	131.7	135	7070	2880	0.109	KRA050	KA050CP0	SA050CP0
KA055CP0	5.5	6	0.25	5.686	5.814	7780	3045	0.113	KRA055	KA055CP0	SA055CP0
KA055CP0	139.7	152.4	6.35	144.4244	147.6756	7780	3045	0.113	KRA055	KA055CP0	SA055CP0
KA060CP0	6	6.5	0.25	6.186	6.314	8440	3200	0.126	KRA060	KA060CP0	SA060CP0
KA060CP0	152.4	165.1	6.35	157.1244	160.3756	8440	3200	0.126	KRA060	KA060CP0	SA060CP0
KA065CP0	6.5	7	0.25	6.686	6.814	9110	3350	0.135	KRA065	KA065CP0	SA065CP0
KA065CP0	165.1	177.8	6.35	169.8244	173.0756	9110	3350	0.135	KRA065	KA065CP0	SA065CP0
KA070CP0	7	7.5	0.25	7.186	7.314	9780	3500	0.141	KRA070	KA070CP0	SA070CP0
KA070CP0	177.8	190.5	6.35	182.5244	185.7756	9780	3500	0.141	KRA070	KA070CP0	SA070CP0
KA075CP0	7.5	8	0.25	7.686	7.814	10440	3640	0.153	KRA075	KA075CP0	SA075CP0
KA075CP0	190.5	203.2	6.35	195.2244	198.4756	10440	3640	0.153	KRA075	KA075CP0	SA075CP0
KA080CP0	8	8.5	0.25	8.186	8.314	11110	3780	0.171	KRA080	KA080CP0	SA080CP0
KA080CP0	203.2	215.9	6.35	207.9244	211.1756	11110	3780	0.171	KRA080	KA080CP0	SA080CP0
KA090CP0	9	9.5	0.25	9.186	9.314	12490	4050	0.198	KRA090	KA090CP0	SA090CP0
KA090CP0	228.6	241.3	6.35	233.3244	236.5756	12490	4050	0.198	KRA090	KA090CP0	SA090CP0
KA100CP0	10	10.5	0.25	10.186	10.314	13820	4300	0.225	KRA100	KA100CP0	SA100CP0
KA100CP0	254	266.7	6.35	258.7244	261.9756	13820	4300	0.225	KRA100	KA100CP0	SA100CP0
KA110CP0	11	11.5	0.25	11.186	11.314	15150	4550	0.234	KRA110	KA110CP0	SA110CP0
KA110CP0	279.4	292.1	6.35	284.1244	287.3756	15150	4550	0.234	KRA110	KA110CP0	SA110CP0
KA120CP0	12	12.5	0.25	12.186	12.314	16530	4790	0.252	KRA120	KA120CP0	SA120CP0
KA120CP0	304.8	317.5	6.35	309.5244	312.7756	16530	4790	0.252	KRA120	KA120CP0	SA120CP0
KB020CP0	2	2.625	0.3125	2.231	2.393	4130	2570	0.073	KRB020	KB020CP0	SB020CP0
KB020CP0	50.8	66.675	7.9375	56.7	60.8	4130	2570	0.073	KRB020	KB020CP0	SB020CP0
KB025CP0	2.5	3.125	0.3125	2.731	2.893	5070	2860	0.091	KRB025	KB025CP0	SB025CP0
KB025CP0	63.5	79.375	7.9375	69.4	73.5	5070	2860	0.091	KRB025	KB025CP0	SB025CP0
KB030CP0	3	3.625	0.3125	3.231	3.393	5960	3150	0.109	KRB030	KB030CP0	SB030CP0
KB030CP0	76.2	92.075	7.9375	82.1	86.2	5960	3150	0.109	KRB030	KB030CP0	SB030CP0
KB035CP0	3.5	4.125	0.3125	3.731	3.893	6850	3400	0.125	KRB035	KB035CP0	SB035CP0
KB035CP0	88.9	104.775	7.9375	94.8	98.9	6850	3400	0.125	KRB035	KB035CP0	SB035CP0
KB040CP0	4	4.625	0.3125	4.432	4.393	7780	3670	0.14	KRB040	KB040CP0	SB040CP0
KB040CP0	101.6	117.475	7.9375	107.5	111.6	7780	3670	0.14	KRB040	KB040CP0	SB040CP0
KB042CP0	4.25	4.875	0.3175	4.481	4.643	8130	3760	0.147	KRB042	KB042CP0	SB042CP0
KB042CP0	107.95	123.825	7.9375	113.8	117.9	8130	3760	0.147	KRB042	KB042CP0	SB042CP0
KB045CP0	4.5	5.125	0.3125	4.731	4.893	8670	3910	0.16	KRB045	KB045CP0	SB045CP0
KB045CP0	114.3	130.175	7.9375	120.2	124.3	8670	3910	0.16	KRB045	KB045CP0	SB045CP0
KB047CP0	4.75	5.375	0.3125	4.981	5.143	9020	4000	0.163	KRB047	KB047CP0	SB047CP0
KB047CP0	120.65	136.525	7.9375	126.6	130.6	9020	4000	0.163	KRB047	KB047CP0	SB047CP0
KB050CP0	5	5.625	0.3125	5.231	5.393	9560	4150	0.172	KRB050	KB050CP0	SB050CP0
KB050CP0	127	142.875	7.9375	132.9	137	9560	4150	0.172	KRB050	KB050CP0	SB050CP0
KB055CP0	5.5	6.125	0.3125	5.731	5.893	10490	4380	0.186	KRB055	KB055CP0	SB055CP0
KB055CP0	139.7	155.575	7.9375	145.6	149.7	10490	4380	0.186	KRB055	KB055CP0	SB055CP0
KB060CP0	6	6.625	0.3125	6.231	6.393	11380	4600	0.205	KRB060	KB060CP0	SB060CP0
KB060CP0	152.4	168.275	7.9375	158.3	162.4	11380	4600	0.205	KRB060	KB060CP0	SB060CP0
KB065CP0	6.5	7.125	0.3125	6.731	6.893	12270	4800	0.216	KRB065	KB065CP0	SB065CP0
KB065CP0	165.1	180.975	7.9375	171	175.1	12270	4800	0.216	KRB065	KB065CP0	SB065CP0
KB070CP0	7	7.625	0.3125	7.231	7.393	13200	5020	0.232	KRB070	KB070CP0	SB070CP0
KB070CP0	177.8	193.675	7.9375	183.7	187.8	13200	5020	0.232	KRB070	KB070CP0	SB070CP0
KB075CP0	7.5	8.125	0.3125	7.731	7.893	14090	5220	0.25	KRB075	KB075CP0	SB075CP0
KB075CP0	190.5	206.375	7.9375	196.4	200.5	14090	5220	0.25	KRB075	KB075CP0	SB075CP0
KB080CP0	8	8.625	0.3125	8.231	8.393	14980	5420	0.262	KRB080	KB080CP0	SB080CP0
KB080CP0	203.2	219.075	7.9375	209.1	213.2	14980	5420	0.262	KRB080	KB080CP0	SB080CP0
KB090CP0	9	9.625	0.3125	9.231	9.393	16800	5800	0.3	KRB090	KB090CP0	SB090CP0
KB090CP0	228.6	244.475	7.9375	234.5	238.6	16800	5800	0.3	KRB090	KB090CP0	SB090CP0
KB100CP0	10	10.625	0.3125	10.231	10.393	18620	6160	0.331	KRB100	KB100CP0	SB100CP0
KB100CP0	254	269.875	7.9375	259.9	264	18620	6160	0.331	KRB100	KB100CP0	SB100CP0
KB110CP0	11	11.625	0.3125	11.231	11.393	20400	6500	0.36	KRB110	KB110CP0	SB110CP0
KB110CP0	279.4	295.275	7.9375	285.3	289.4	20400	6500	0.36	KRB110	KB110CP0	SB110CP0
KB120CP0	12	12.625	0.3125	12.231	12.393	22230	6840	0.39	KRB120	KB120CP0	SB120CP0
KB120CP0	304.8	320.675	7.9375	310.7	314.8	22230	6840	0.39	KRB120	KB120CP0	SB120CP0
KB140CP0	14	14.625	0.3125	14.231	14.393	25830	7470	0.476	KRB140	KB140CP0	SB140CP0
KB140CP0	355.6	371.475	7.9375	361.5	365.6	25830	7470	0.476	KRB140	KB140CP0	SB140CP0
KB160CP0	16	16.625	0.3125	16.231	16.393	29430	8060	0.544	KRB160	KB160CP0	SB160CP0
KB160CP0	406.4	422.275	7.9375	412.3	416.4	29430	8060	0.544	KRB160	KB160CP0	SB160CP0
KB180CP0	18	18.625	0.3125	18.231	18.393	33070	8600	0.612	KRB180	KB180CP0	SB180CP0
KB180CP0	457.2	473.075	7.9375	463.1	467.2	33070	8600	0.612	KRB180	KB180CP0	SB180CP0
KB200CP0	20	20.625	0.3125	20.231	20.393	36670	9130	0.68	KRB200	KB200CP0	SB200CP0
KB200CP0	508	523.875	7.9375	513.9	518	36670	9130	0.68	KRB200	KB200CP0	SB200CP0
KC040CP0	4	4.75	0.375	4.277	4.473	9330	4770	0.204	KRC040	KC040CP0	SC040CP0
KC040CP0	101.6	120.65	9.525	108.6	113.6	9330	4770	0.204	KRC040	KC040CP0	SC040CP0
KC042CP0	4.25	5	0.375	4.527	4.723	9780	4920	0.213	KRC042	KC042CP0	SC042CP0
KC042CP0	107.95	127	9.525	115	120	9780	4920	0.213	KRC042	KC042CP0	SC042CP0
KC045CP0	4.5	5.25	0.375	4.777	4.973	10400	5080	0.225	KRC045	KC045CP0	SC045CP0
KC045CP0	114.3	133.35	9.525	121.3	126.3	10400	5080	0.225	KRC045	KC045CP0	SC045CP0
KC047CP0	4.75	5	0.375	5.027	5.223	10930	5230	0.235	KRC047	KC047CP0	SC047CP0
KC047CP0	120.65	139.7	9.525	127.7	132.7	10930	5230	0.235	KRC047	KC047CP0	SC047CP0
KC050CP0	5	5.75	0.375	5.277	5.473	11510	5380	0.263	KRC050	KC050CP0	SC050CP0
KC050CP0	127	146.05	9.525	134	139	11510	5380	0.263	KRC050	KC050CP0	SC050CP0
KC055CP0	5.5	6.25	0.375	5.777	5.973	12580	5670	0.268	KRC055	KC055CP0	SC055CP0
KC055CP0	139.7	158.75	9.525	146.7	151.7	12580	5670	0.268	KRC055	KC055CP0	SC055CP0
KC060CP0	6	6.75	0.375	6.277	6.473	13650	5950	0.295	KRC060	KC060CP0	SC060CP0
KC060CP0	152.4	171.45	9.525	159.4	164.4	13650	5950	0.295	KRC060	KC060CP0	SC060CP0
KC065CP0	6.5	7.25	0.375	6.777	6.973	14710	6210	0.312	KRC065	KC065CP0	SC065CP0
KC065CP0	165.1	184.15	9.525	172.1	177.1	14710	6210	0.312	KRC065	KC065CP0	SC065CP0
KC070CP0	7	7.75	0.375	7.277	7.473	15780	6480	0.34	KRC070	KC070CP0	SC070CP0
KC070CP0	177.8	196.85	9.525	184.4	189.8	15780	6480	0.34	KRC070	KC070CP0	SC070CP0
KC075CP0	7.5	8.25	0.375	7.777	7.973	16850	6730	0.36	KRC075	KC075CP0	SC075CP0
KC075CP0	190.5	209.55	9.525	197.5	202.5	16850	6730	0.36	KRC075	KC075CP0	SC075CP0
KC080CP0	8	8.75	0.375	8.277	8.473	17910	6980	0.387	KRC080	KC080CP0	SC080CP0
KC080CP0	203.2	222.25	9.525	210.2	215.2	17910	6980	0.387	KRC080	KC080CP0	SC080CP0
KC090CP0	9	9.75	0.375	9.277	9.473	20050	7460	0.45	KRC090	KC090CP0	SC090CP0
KC090CP0	228.6	247.65	9.525	235.6	240.6	20050	7460	0.45	KRC090	KC090CP0	SC090CP0
KC100CP0	10	10.75	0.375	10.277	10.473	22180	7900	0.481	KRC100	KC100CP0	SC100CP0
KC100CP0	254	273.05	9.525	261	266	22180	7900	0.481	KRC100	KC100CP0	SC100CP0
KC110CP0	11	11.75	0.375	11.277	11.473	24310	8360	0.526	KRC110	KC110CP0	SC110CP0
KC110CP0	279.4	298.45	9.525	286.4	291.4	24310	8360	0.526	KRC110	KC110CP0	SC110CP0
KC120CP0	12	12.75	0.375	12.277	12.473	26450	8780	0.567	KRC120	KC120CP0	SC120CP0
KC120CP0	304.8	323.85	9.525	311.8	316.8	26450	8780	0.567	KRC120	KC120CP0	SC120CP0
KC140CP0	14	14.75	0.375	14.277	14.473	30720	9580	0.689	KRC140	KC140CP0	SC140CP0
KC140CP0	355.6	374.65	9.525	362.6	367.6	30720	9580	0.689	KRC140	KC140CP0	SC140CP0
KC160CP0	16	16.75	0.375	16.277	16.473	35030	10320	0.785	KRC160	KC160CP0	SC160CP0
KC160CP0	406.4	425.45	9.525	413.4	418.4	35030	10320	0.785	KRC160	KC160CP0	SC160CP0
KC180CP0	18	18.75	0.375	18.277	18.473	39290	11020	0.88	KRC180	KC180CP0	SC180CP0
KC180CP0	457.2	476.25	9.525	464.2	469.2	39290	11020	0.88	KRC180	KC180CP0	SC180CP0
KC200CP0	20	20.75	0.375	20.277	20.473	43560	11680	0.98	KRC200	KC200CP0	SC200CP0
KC200CP0	508	527.05	9.525	515.04	520	43560	11680	0.98	KRC200	KC200CP0	SC200CP0
KC250CP0	25	25.75	0.375	25.277	25.473	54230	13160	1.22	KRC250	KC250CP0	SC250CP0
KC250CP0	635	654.05	9.525	642.04	647.01	54230	13160	1.22	KRC250	KC250CP0	SC250CP0
KC300CP0	30	30.75	0.375	30.277	30.473	64940	14490	1.46	KRC300	KC300CP0	SC300CP0
KC300CP0	762	781.05	9.525	769.04	774.01	64940	14490	1.46	KRC300	KC300CP0	SC300CP0
KD040CP0	4	5	0.5	4.37	4.63	13690	7800	0.366	KRD040	KD040CP0	SD040CP0
KD040CP0	101.6	127	12.7	111	117.6	13690	7800	0.366	KRD040	KD040CP0	SD040CP0
KD042CP0	4.25	5.25	0.5	4.62	4.88	14180	7950	0.386	KRD042	KD042CP0	SD042CP0
KD042CP0	107.95	133.35	12.7	117.3	124	14180	7950	0.386	KRD042	KD042CP0	SD042CP0
KD045CP0	4.5	5.5	0.5	4.87	5.13	15200	8280	0.405	KRD045	KD045CP0	SD045CP0
KD045CP0	114.3	139.7	12.7	123.7	130.3	15200	8280	0.405	KRD045	KD045CP0	SD045CP0
KD047CP0	4.75	5.75	0.5	5.12	5.38	15690	8410	0.426	KRD047	KD047CP0	SD047CP0
KD047CP0	120.65	146.05	12.7	130	136.7	15690	8410	0.426	KRD047	KD047CP0	SD047CP0
KD050CP0	5	6	0.5	5.37	5.63	16710	8730	0.454	KRD050	KD050CP0	SD050CP0
KD050CP0	127	152.4	12.7	136.4	143	16710	8730	0.454	KRD050	KD050CP0	SD050CP0
KD055CP0	5.5	6.5	0.5	5.87	6.13	18230	9170	0.485	KRD055	KD055CP0	SD055CP0
KD055CP0	139.7	165.1	12.7	149.1	155.7	18230	9170	0.485	KRD055	KD055CP0	SD055CP0
KD060CP0	6	7	0.5	6.37	6.63	19780	9600	0.526	KRD060	KD060CP0	SD060CP0
KD060CP0	152.4	177.8	12.7	161.8	168.4	19780	9600	0.526	KRD060	KD060CP0	SD060CP0
KD065CP0	6.5	7.5	0.5	6.87	7.13	21290	10020	0.566	KRD065	KD065CP0	SD065CP0
KD065CP0	165.1	190.5	12.7	174.5	181.1	21290	10020	0.566	KRD065	KD065CP0	SD065CP0
KD070CP0	7	8	0.5	7.37	7.63	22800	10420	0.606	KRD070	KD070CP0	SD070CP0
KD070CP0	177.8	203.2	12.7	187.2	193.8	22800	10420	0.606	KRD070	KD070CP0	SD070CP0
KD075CP0	7.5	8.5	0.5	7.87	8.13	24310	10820	0.65	KRD075	KD075CP0	SD075CP0
KD075CP0	190.5	215.9	12.7	199.9	206.5	24310	10820	0.65	KRD075	KD075CP0	SD075CP0
KD080CP0	8	9	0.5	8.37	8.63	25830	11200	0.694	KRD080	KD080CP0	SD080CP0
KD080CP0	203.2	228.6	12.7	212.6	219.2	25830	11200	0.694	KRD080	KD080CP0	SD080CP0
KD090CP0	9	10	0.5	9.37	9.63	28890	11950	0.78	KRD090	KD090CP0	SD090CP0
KD090CP0	228.6	254	12.7	238	244.6	28890	11950	0.78	KRD090	KD090CP0	SD090CP0
KD100CP0	10	11	0.5	10.37	10.63	31920	12660	0.853	KRD100	KD100CP0	SD100CP0
KD100CP0	254	279.4	12.7	263.4	270	31920	12660	0.853	KRD100	KD100CP0	SD100CP0
KD110CP0	11	12	0.5	11.37	11.63	34980	13340	0.934	KRD110	KD110CP0	SD110CP0
KD110CP0	279.4	304.8	12.7	288.8	295.4	34980	13340	0.934	KRD110	KD110CP0	SD110CP0
KD120CP0	12	13	0.5	12.37	12.63	38010	14000	1.02	KRD120	KD120CP0	SD120CP0
KD120CP0	304.8	330.2	12.7	314.2	320.8	38010	14000	1.02	KRD120	KD120CP0	SD120CP0
KD140CP0	14	15	0.5	14.37	14.63	44090	15230	1.24	KRD140	KD140CP0	SD140CP0
KD140CP0	355.6	381	12.7	365	371.6	44090	15230	1.24	KRD140	KD140CP0	SD140CP0
KD160CP0	16	17	0.5	16.37	16.63	50180	16400	1.41	KRD160	KD160CP0	SD160CP0
KD160CP0	406.4	431.8	12.7	415.8	422.4	50180	16400	1.41	KRD160	KD160CP0	SD160CP0
KD180CP0	18	19	0.5	18.37	18.63	56230	17480	1.58	KRD180	KD180CP0	SD180CP0
KD180CP0	457.2	482.6	12.7	466.6	473.2	56230	17480	1.58	KRD180	KD180CP0	SD180CP0
KD200CP0	20	21	0.5	20.37	20.63	62320	18510	1.75	KRD200	KD200CP0	SD200CP0
KD200CP0	508	533.4	12.7	517.4	524	62320	18510	1.75	KRD200	KD200CP0	SD200CP0
KD210CP0	21	22	0.5	21.37	21.63	65370	18990	1.83	KRD210	KD210CP0	SD210CP0
KD210CP0	533.4	558.8	12.7	542.798	549.402	65370	18990	1.83	KRD210	KD210CP0	SD210CP0
KD250CP0	25	26	0.5	25.37	25.63	77520	20840	2.17	KRD250	KD250CP0	SD250CP0
KD250CP0	635	660.4	12.7	644.398	651.002	77520	20840	2.17	KRD250	KD250CP0	SD250CP0
KD300CP0	30	31	0.5	30.37	30.36	92720	22900	2.6	KRD300	KD300CP0	SD300CP0
KD300CP0	762	787.4	12.7	771.398	771.144	92720	22900	2.6	KRD300	KD300CP0	SD300CP0
KF040CP0	4	5.5	0.75	4.555	4.945	23830	15820	0.875	KRF040	KF040CP0	SF040CP0
KF040CP0	101.6	139.7	19.05	115.7	125.6	23830	15820	0.875	KRF040	KF040CP0	SF040CP0
KF042CP0	4.25	5.75	0.75	4.805	5.195	25070	16250	0.93	KRF042	KF042CP0	SF042CP0
KF042CP0	107.95	146.05	19.05	122	132	25070	16250	0.93	KRF042	KF042CP0	SF042CP0
KF045CP0	4.5	6	0.75	5.055	5.445	26360	16670	0.975	KRF045	KF045CP0	SF045CP0
KF045CP0	114.3	152.4	19.05	128.4	138.3	26360	16670	0.975	KRF045	KF045CP0	SF045CP0
KF047CP0	4.75	6.25	0.75	5.305	5.695	27600	17080	1.04	KRF047	KF047CP0	SF047CP0
KF047CP0	120.65	158.75	19.05	134.7	144.7	27600	17080	1.04	KRF047	KF047CP0	SF047CP0
KF050CP0	5	6.5	0.75	5.555	5.945	28850	17500	1.09	KRF050	KF050CP0	SF050CP0
KF050CP0	127	165.1	19.05	141.1	151	28850	17500	1.09	KRF050	KF050CP0	SF050CP0
KF055CP0	5.5	7	0.75	6.055	6.445	31340	18300	1.18	KRF055	KF055CP0	SF055CP0
KF055CP0	139.7	177.8	19.05	153.8	163.7	31340	18300	1.18	KRF055	KF055CP0	SF055CP0
KF060CP0	6	7.5	0.75	6.555	6.945	33870	19070	1.24	KRF060	KF060CP0	SF060CP0
KF060CP0	152.4	190.5	19.05	166.5	176.4	33870	19070	1.24	KRF060	KF060CP0	SF060CP0
KF065CP0	6.5	8	0.75	7.055	7.445	36360	19830	1.35	KRF065	KF065CP0	SF065CP0
KF065CP0	165.1	203.2	19.05	179.2	189.1	36360	19830	1.35	KRF065	KF065CP0	SF065CP0
KF070CP0	7	8.5	0.75	7.555	7.945	38890	20570	1.45	KRF070	KF070CP0	SF070CP0
KF070CP0	177.8	215.9	19.05	191.9	201.8	38890	20570	1.45	KRF070	KF070CP0	SF070CP0
KF075CP0	7.5	9	0.75	8.055	8.445	41380	21300	1.56	KRF075	KF075CP0	SF075CP0
KF075CP0	190.5	228.6	19.05	204.6	214.5	41380	21300	1.56	KRF075	KF075CP0	SF075CP0
KF080CP0	8	9.5	0.75	8.555	8.945	43920	22000	1.66	KRF080	KF080CP0	SF080CP0
KF080CP0	203.2	241.3	19.05	217.3	227.2	43920	22000	1.66	KRF080	KF080CP0	SF080CP0
KF090CP0	9	10.5	0.75	9.555	9.945	48900	23370	1.81	KRF090	KF090CP0	SF090CP0
KF090CP0	228.6	266.7	19.05	242.7	252.6	48900	23370	1.81	KRF090	KF090CP0	SF090CP0
KF100CP0	10	11.5	0.75	10.555	10.945	53920	24680	2.02	KRF100	KF100CP0	SF100CP0
KF100CP0	254	292.1	19.05	268.1	278	53920	24680	2.02	KRF100	KF100CP0	SF100CP0
KF110CP0	11	12.5	0.75	11.555	11.945	58940	25930	2.18	KRF110	KF110CP0	SF110CP0
KF110CP0	279.4	317.5	19.05	293.5	303.4	58940	25930	2.18	KRF110	KF110CP0	SF110CP0
KF120CP0	12	13.5	0.75	12.555	12.945	63960	27140	2.38	KRF120	KF120CP0	SF120CP0
KF120CP0	304.8	342.9	19.05	318.9	328.3	63960	27140	2.38	KRF120	KF120CP0	SF120CP0
KF140CP0	14	15.5	0.75	14.555	14.945	74010	29430	2.72	KRF140	KF140CP0	SF140CP0
KF140CP0	355.6	393.7	19.05	369.7	379.6	74010	29430	2.72	KRF140	KF140CP0	SF140CP0
KF160CP0	16	17.5	0.75	16.555	16.945	84010	31580	3.22	KRF160	KF160CP0	SF160CP0
KF160CP0	406.4	444.5	19.05	420.5	430.4	84010	31580	3.22	KRF160	KF160CP0	SF160CP0
KF180CP0	18	19.5	0.75	18.555	18.945	94060	33600	3.58	KRF180	KF180CP0	SF180CP0
KF180CP0	457.2	495.3	19.05	471.3	481.2	94060	33600	3.58	KRF180	KF180CP0	SF180CP0
KF200CP0	20	21.5	0.75	20.555	20.945	104100	35500	4.04	KRF200	KF200CP0	SF200CP0
KF200CP0	508	546.1	19.05	522.1	532	104100	35500	4.04	KRF200	KF200CP0	SF200CP0
KF250CP0	25	26.5	0.75	25.555	25.945	129180	39840	4.94	KRF250	KF250CP0	SF250CP0
KF250CP0	635	673.1	19.05	649.097	659.003	129180	39840	4.94	KRF250	KF250CP0	SF250CP0
KF300CP0	30	31.5	0.75	30.555	30.945	154250	43680	5.89	KRF300	KF300CP0	SF300CP0
KF300CP0	762	800.1	19.05	776.097	786.003	154250	43680	5.89	KRF300	KF300CP0	SF300CP0
KF350CP0	35	36.5	0.75	35.555	35.945	179360	47130	6.85	KRF350	KF350CP0	SF350CP0
KF350CP0	889	927.1	19.05	903.097	913.003	179360	47130	6.85	KRF350	KF350CP0	SF350CP0
KF400CP0	40	41.5	0.75	40.555	40.945	204430	50240	7.81	KRF400	KF400CP0	SF400CP0
KF400CP0	1016	1054.1	19.05	1030.097	1040.003	204430	50240	7.81	KRF400	KF400CP0	SF400CP0
KG040CP0	4	6	1	4.742	5.258	36490	27180	1.63	KRG040	KG040CP0	SG040CP0
KG040CP0	101.6	152.4	25.4	120.4	133.6	36490	27180	1.63	KRG040	KG040CP0	SG040CP0
KG042CP0	4.25	6.25	1	4.992	5.508	36490	26940	1.72	KRG042	KG042CP0	SG042CP0
KG042CP0	107.95	158.75	25.4	126.8	139.9	36490	26940	1.72	KRG042	KG042CP0	SG042CP0
KG045CP0	4.5	6.5	1	5.242	5.758	38940	27900	1.81	KRG045	KG045CP0	SG045CP0
KG045CP0	114.3	165.1	25.4	133.1	146.3	38940	27900	1.81	KRG045	KG045CP0	SG045CP0
KG047CP0	4.75	6.75	1	5.492	6.008	41340	28830	1.86	KRG047	KG047CP0	SG047CP0
KG047CP0	120.65	171.45	25.4	139.5	152.6	41340	28830	1.86	KRG047	KG047CP0	SG047CP0
KG050CP0	5	7	1	5.742	6.258	43780	29740	1.95	KRG050	KG050CP0	SG050CP0
KG050CP0	127	177.8	25.4	145.8	159	43780	29740	1.95	KRG050	KG050CP0	SG050CP0
KG055CP0	5.5	7.5	1	6.242	6.758	46230	30450	2.13	KRG055	KG055CP0	SG055CP0
KG055CP0	139.7	190.5	25.4	158.5	171.7	46230	30450	2.13	KRG055	KG055CP0	SG055CP0
KG060CP0	6	8	1	6.742	7.258	51070	32190	2.31	KRG060	KG060CP0	SG060CP0
KG060CP0	152.4	203.2	25.4	171.2	184.4	51070	32190	2.31	KRG060	KG060CP0	SG060CP0
KG065CP0	6.5	8.5	1	7.242	7.758	53520	32860	2.45	KRG065	KG065CP0	SG065CP0
KG065CP0	165.1	215.9	25.4	183.9	197.1	53520	32860	2.45	KRG065	KG065CP0	SG065CP0
KG070CP0	7	9	1	7.742	8.258	58360	34510	2.63	KRG070	KG070CP0	SG070CP0
KG070CP0	177.8	228.6	25.4	196.6	209.8	58360	34510	2.63	KRG070	KG070CP0	SG070CP0
KG075CP0	7.5	9.5	1	8.242	8.758	60810	35160	2.77	KRG075	KG075CP0	SG075CP0
KG075CP0	190.5	241.3	25.4	209.3	222.5	60810	35160	2.77	KRG075	KG075CP0	SG075CP0
KG080CP0	8	10	1	8.742	9.258	65650	36740	2.95	KRG080	KG080CP0	SG080CP0
KG080CP0	203.2	254	25.4	222	235.2	65650	36740	2.95	KRG080	KG080CP0	SG080CP0
KG090CP0	9	11	1	9.742	10.258	72990	38870	3.27	KRG090	KG090CP0	SG090CP0
KG090CP0	228.6	279.4	25.4	247.4	260.6	72990	38870	3.27	KRG090	KG090CP0	SG090CP0
KG100CP0	10	12	1	10.742	11.258	80280	40910	3.58	KRG100	KG100CP0	SG100CP0
KG100CP0	254	304.8	25.4	272.8	286	80280	40910	3.58	KRG100	KG100CP0	SG100CP0
KG110CP0	11	13	1	11.742	12.258	87570	42890	3.9	KRG110	KG110CP0	SG110CP0
KG110CP0	279.4	330.2	25.4	298.2	311.4	87570	42890	3.9	KRG110	KG110CP0	SG110CP0
KG120CP0	12	14	1	12.742	13.258	94860	44780	4.22	KRG120	KG120CP0	SG120CP0
KG120CP0	304.8	355.6	25.4	323.6	336.8	94860	44780	4.22	KRG120	KG120CP0	SG120CP0
KG140CP0	14	16	1	14.742	15.258	109440	48390	4.9	KRG140	KG140CP0	SG140CP0
KG140CP0	355.6	406.4	25.4	374.4	387.6	109440	48390	4.9	KRG140	KG140CP0	SG140CP0
KG160CP0	16	18	1	16.742	17.258	124060	51780	5.58	KRG160	KG160CP0	SG160CP0
KG160CP0	406.4	457.2	25.4	425.2	438.4	124060	51780	5.58	KRG160	KG160CP0	SG160CP0
KG180CP0	18	20	1	18.742	19.258	138640	54980	6.21	KRG180	KG180CP0	SG180CP0
KG180CP0	457.2	508	25.4	476	489.2	138640	54980	6.21	KRG180	KG180CP0	SG180CP0
KG200CP0	20	22	1	20.742	21.258	153220	57980	7.17	KRG200	KG200CP0	SG200CP0
KG200CP0	508	558.8	25.4	526.8	540	153220	57980	7.17	KRG200	KG200CP0	SG200CP0
KG220CP0	22	24	1	22.742	23.258	167840	60830	7.62	KRG220	KG220CP0	SG220CP0
KG220CP0	558.8	609.6	25.4	577.6468	590.7532	167840	60830	7.62	KRG220	KG220CP0	SG220CP0
KG250CP0	25	27	1	25.742	26.258	189720	64860	8.85	KRG250	KG250CP0	SG250CP0
KG250CP0	635	685.8	25.4	653.8468	666.9532	189720	64860	8.85	KRG250	KG250CP0	SG250CP0
KG300CP0	30	32	1	30.742	31.258	226220	70960	10.57	KRG300	KG300CP0	SG300CP0
KG300CP0	762	812.8	25.4	780.8468	793.9532	226220	70960	10.57	KRG300	KG300CP0	SG300CP0
KG350CP0	35	37	1	35.742	36.258	262710	76430	12.29	KRG350	KG350CP0	SG350CP0
KG350CP0	889	939.8	25.4	907.8468	920.9532	262710	76430	12.29	KRG350	KG350CP0	SG350CP0
KG400CP0	40	42	1	40.742	41.258	299210	81380	13.97	KRG400	KG400CP0	SG400CP0
KG400CP0	1016	1066.8	25.4	1034.8468	1047.9532	299210	81380	13.97	KRG400	KG400CP0	SG400CP0

Maintenance and Lubrication

Proper maintenance and lubrication are essential to maximize the performance and lifespan of Type C bearings. Regular inspection, lubrication, and adherence to manufacturer guidelines will ensure optimal functionality over an extended period.

Conclusion

Open Type Thin Section Radial Contact Ball Bearings (Type C) offer a compact and precise solution for applications requiring reliable radial load support. Their slim design, high precision, and versatility make them a preferred choice in industries where space optimization and precision are paramount. Whether in robotics, medical devices, aerospace, or automation, Type C bearings contribute to the efficiency and performance of various applications.

For expert guidance in meeting your specific requirements, reach out to our knowledgeable team. Experience firsthand how our precision solutions can elevate your machinery’s efficiency and durability. Contact us today!

LKPB With more than 10 years of production experience

Supporting OEM service; 50 days return service; 7*24 hours technical support; Accept non-standard customization; Maximum 24 months product warranty

FAQ

What is LKPB?

Luoyang LIKE Precision Machinery Co., Ltd – LKPB，Located in Luoyang, which is a bearing manufacturing base in China, we are an enterprise focusing on the research, development and manufacture of precision bearings, mainly producing precision crossed roller bearings and rotary table bearings and various non-standard bearings with precision class of P5, P4 , P2 and VSP.

Are your products reliable?

The company strictly follows the ISO9001 quality system requirements for product quality control, relying on the professional technology of the bearing production base, the product quality is stable and cost-effective, and is well received by customers at home and abroad. The company adheres to the concept of “openness, professionalism and responsibility”, and strives to become a professional bearing application service provider. Welcome customers to negotiate, looking forward to sincere cooperation with you, willing to achieve a win-win situation with you!

Do you have export experience?

Luoyang LIKE Precisoin Machinery Co., Ltd has accumulated rich production experience in the past 10 years, supporting OEM service. Our products are exported to Germany, Italy, Korea, Japan, the United States, Belgium, Turkey and so on.

Contact information for LKPB?

Tel: 0086-379 63123369
WhatsApp/Wechat: 86 15670310586
Email: info@lkpbearing.com

What types of bearings do you mainly produce?

Top quality: Rotary Table Bearing ( YRT, YRTS, YRTM, ZKLDF series) ; Crossed Roller Bearing ( RA/RAU, RB, RU, RE, SX, XU, XSU, XR/JXR, CRB/CRBC, CRBH, CRBF, CRBS, CRBT series); Thin Section Bearings ( KAA, KA, KB, KC, KD, KF, KG, JHA, JA, JB, JG, JU series); Harmonic Reducer Bearings ( CSF, SHF series); Angular Contact Ball Bearing ( 718, 719, 70, 72 series); Hollow Rotary Platform Bearings ( ZK series); and Flexible Bearings ( F series, 3E series).

Does it support OEM?

Yes, We have experience working in this area

What are the application areas of bearings?

The main application areas of our products are precision rotary tables, machining center rotary tables, industrial robot joints and rotating, robotic rotating parts, CNC machine tools, automation industry, direct drive motors, precision instruments, radar, medical equipment and other industries.

How long does the order cycle take?

Regular models are in stock, reasonable prices, ready for delivery, non-standard precision bearings according to the requirements of the drawings and the number of 1-3 weeks delivery time

Please let us know the model and quantity of the product you need and we will get back to you as soon as possible!

Open Type Thin Section Radial Contact Ball Bearings (Type C)

Introduction

Table of Contents

Open Type Thin Section Radial Contact Ball Bearings (Type C) are classified as follows

Open Type Thin Section Radial Contact Ball Bearings (Type C) Product Features

1. Slim Design:

2. Radial Contact:

3. High Precision:

4. Axial Load Capability:

5. Versatility:

Open Type Thin Section Radial Contact Ball Bearings (Type C) Applications

1. Robotics:

2. Medical Devices:

3. Aerospace:

4. Automation:

Open Type Thin Section Radial Contact Ball Bearings (Type C) Product model

Maintenance and Lubrication

Conclusion

LKPB With more than 10 years of production experience

Please let us know the model and quantity of the product you need and we will get back to you as soon as possible!

FAQ

What is LKPB?

Are your products reliable?

Do you have export experience?

Contact information for LKPB?

What types of bearings do you mainly produce?

Does it support OEM?

What are the application areas of bearings?

How long does the order cycle take?

Please let us know the model and quantity of the product you need and we will get back to you as soon as possible!

Please let us know the model and quantity of the product you need and we will get back to you as soon as possible!

Open Type Thin Section Radial Contact Ball Bearings (Type C)

Introduction

Table of Contents

Open Type Thin Section Radial Contact Ball Bearings (Type C) are classified as follows

Open Type Thin Section Radial Contact Ball Bearings (Type C) Product Features

1. Slim Design:

2. Radial Contact:

3. High Precision:

4. Axial Load Capability:

5. Versatility:

Open Type Thin Section Radial Contact Ball Bearings (Type C) Applications

1. Robotics:

2. Medical Devices:

3. Aerospace:

4. Automation:

Open Type Thin Section Radial Contact Ball Bearings (Type C) Product model

Maintenance and Lubrication

Conclusion

LKPB With more than 10 years of production experience

Please let us know the model and quantity of the product you need and we will get back to you as soon as possible!

FAQ

Please let us know the model and quantity of the product you need and we will get back to you as soon as possible!

We respect your choice of cookies. We use cookies to improve your experience on our website. By browsing this site, you consent to our use of cookies.

LKPB®
